Since the early 1960's, EARL's
performance products, has been providing quality fluid control plumbing products to the high performance market and established
itself as the leading supplier to professional racers, the world over.
Because of this, we are proud to supply our customers with the finest in
performance plumbing products from Earl's. Let us help you set up your fluid
control systems today!
See our other pages for fitting and adapters.
Earl's Performance Products
Hose
- Perform-O-Flex tm Hose
- Stainless braid-protected synthetic rubber hose
- Reinforced hose liner bonded to outer protective sheath
- Remains flexible at temperatures between -40 and +300 degrees F
- Perform-O-Flex hose is not to be used with brake fluid
Hose Size |
I.D.
|
O.D.
|
Max.Operating
|
Max.Clamped
|
Minimum Bend
|
| - 6 | 0.34 | 0.55 | 1500 | 250 | 2.25" |
| - 8 | 0.44 | 0.64 | 1500 | 250 | 3.5" |
| - 10 | 0.56 | 0.80 | 1250 | 250 | 4.0" |
| - 12 | 0.69 | 0.94 | 1000 | 250 | 4.5" |
| - 16 | 0.88 | 1.16 | 750 | 250 | 5.5" |
* When used with Auto-Fit™
or Swivel-Seal™ hose ends
** Pressure limiting factor
will be the hose clamp. The hose limit far exceeds any pressure available
by clamping.
Do not reassemble a hose without trimming the end, to provide a clean sealing surface.
Typical Oil System Scenario for help in configuring and ordering quality Earl's hose, fittings and adapters.
Constructed in the US, the Pro-Lite 350 hose has a tough, abrasion resistant Nylon sheathing, bonded to the textile inner braid, embedded in the synthetic rubber liner. This gives the hose incredible flexibility while maintaining the ability to withstand high vacuum and hot oil temperatures.
- Pro-Lite 350 tm Hose
- Nylon braid-protected synthetic rubber hose
- Highest pressure lightweight rubber lined hose available
- Half the weight of traditional Stainless braid hose
- Easy to cut and work with
- Reinforced hose liner bonded to outer protective sheath
- Remains flexible at temperatures between -40 and +300 degrees F
- Pro-Lite 350 hose is not to be used with brake fluid
Hose Size |
I.D.
|
O.D.
|
Max.Operating
|
Minimum Bend
|
| - 6 | 0.35 | 0.55 | 350 | 2.25" |
| - 8 | 0.44 | 0.65 | 350 | 3.5" |
| - 10 | 0.57 | 0.80 | 350 | 4.0" |
| - 12 | 0.69 | 0.94 | 350 | 4.5" |
| - 16 | 0.88 | 1.16 | 300 | 5.5" |
* When used with Auto-Fit™ or Swivel-Seal™ or Auto-Crimp hose ends
The use of other manufactures hose ends is not
recommended and may compromise the pressure capabilities and durability of the
hose.
Do
not reassemble a hose without trimming the end, to provide a clean sealing
surface.
- Super Stock Hose
- Synthetic rubber hose reinforced by a full coverage interior braided fabric
- For use with Earl's Super Stock fit hose ends only
- Rated at 250psi and 250 degrees F continuous service
- Suitable for fuel, oil and water
- Standard color black or blue
| Hose Size | I.D. Inch |
O.D. Inch |
Working Pressure (psi) |
Minimum Bend Radius |
| - 4 | .25 | .47 | 250 | 2.5" |
| - 6 | .375 | .625 | 250 | 3.0" |
| - 8 | .50 | .75 | 250 | 5.0" |
| - 10 | .625 | .95 | 250 | 6.0" |
| - 12 | .75 | 1.05 | 250 | 7.0" |
Extra heat protection when used with Earl's Flame Guard insulation.
- Speed-Flex tm Hose
- Extruded Teflon inner line
- Tightly woven high tensile stainless steel outer braid limits expansion
- .040" aircraft specification wall thickness (not commercial .030")
- Recommend size -3 for brakes, size -4 for hydraulic clutch systems
| Hose Size |
I.D. | Max.Operating Pressure (psi) |
Minimum Bend Radius |
Operating Temperature |
| - 3 | 1/8" | 2000 | 1-1/2" | -65 to 450F |
| - 4 | 3/16" | 2000 | 1-1/2" | -65 to 450F |
Contact us for your race plumbing needs!
